振框式平筛vibrating screen
用途/特点
该设备用于废纸浆的粗筛，也可用于压力筛尾浆的筛选，用于处理稍大的杂质如塑料、橡胶、乙烯、乙烯基氯化物等杂志。具有结构简单，排渣能力大，操作维修方便等特点。
该设备有孔筛板和缝筛板两种，其中孔筛用于粗筛，缝筛用于压力筛尾浆处理。
application/ features
the equipment is used for the pulp rough screen and reject screening of pressure screen, to process larger impurities such as plastics, rubber, vinyl chloride and other impurities. simple structure , the great elimination capability of slag, convenient operation and maintenance features.
the equipment has hole screen plate and joint screen plate, of which hole screen plate is for the disposal of pressure screen reject.
主要技术参数main technical parameters
|
型号type |
zsk5 |
zsk4 |
zsk6 |
zsk7 |
|||||
|
筛选面积screen area（㎡） |
1 |
2 |
3 |
4 |
|||||
|
进浆浓度concentration of feeding pulp |
孔筛hole screen（%） |
1.2~1.5 |
|||||||
|
缝筛slot screen（%） |
0.5~0.8 |
||||||||
|
生产能力capacity：t/d |
处理尾浆 treating tail pulp |
孔筛hole screen（t/d） |
4.5~15 |
9~30 |
13.5~45 |
18~60 |
|||
|
缝筛slot screen（t/d） |
2~4.5 |
4~9 |
6~13.5 |
8~18 |
|||||
|
主流程 main flow |
孔筛hole screen（t/d） |
7.5~25 |
15~50 |
22.5~75 |
30~100 |
||||
|
缝筛slot screen（t/d） |
3.5~7.5 |
7~15 |
10.5~22.5 |
14~30 |
|||||
|
电机功率motor（ｋｗ） |
2..2 |
2.2 |
4 |
5.5 |
|||||
|
外形尺寸(长l×宽w×高h)：mm |
2860×1950×1370 |
2760×2560×1440 |
2790×3220×1440 |
3445×3500×1440 |
|||||
|
