vibration framed flat screen vibrating screen
uses / features
the coarse sieve apparatus for waste paper pulp , the screen can also be used for pressure screening tail rotor for processing slightly impurities such as plastics, rubber, ethylene , vinyl chloride, etc. magazines . has a simple structure , large slag capacity , easy operation and maintenance.
the device has two holes sieve sieve and joints, which hole sieve for coarse sieve, sieve slit tail pressure screen for pulp processing .
application / features
the equipment is used for the pulp rough screen and reject screening of pressure screen, to process larger impurities such as plastics, rubber, vinyl chloride and other impurities. simple structure, the great elimination capability of slag, convenient operation and maintenance features.
the equipment has hole screen plate and joint screen plate, of which hole screen plate is for the disposal of pressure screen reject.
the main technical parameters main technical parameters
model type zsk5 zsk4 zsk6 zsk7
screening area screen area ( m ) 1234
into the plasma concentration concentration of feeding pulp hole sieve hole screen (%) 1.2 ~ 1.5
slotted screen slot screen (%) 0.5 ~ 0.8
production capacity capacity: t / d processing tail rotor
treating tail pulp sieve hole screen (t / d) 4.5 ~ 15 9 ~ 30 13.5 ~ 45 18 ~ 60
slotted screen slot screen (t / d) 2 ~ 4.5 4 ~ 9 6 ~ 13.5 8 ~ 18
main flow
main flow sieve hole screen (t / d) 7.5 ~ 25 15 ~ 50 22.5 ~ 75 30 ~ 100
slotted screen slot screen (t / d) 3.5 ~ 7.5 7 ~ 15 10.5 ~ 22.5 14 ~ 30
motor power motor (kw) 2 .. 2 2.2 4 5.5
dimensions ( length l × w w × height h): mm 2860 × 1950 × 1370 2760 × 2560 × 1440 2790 × 3220 × 1440 3445 × 3500 × 1440
