ⅰ. overview
the high concentration hydrapulper is the indispensable equipment for wastepaper deinking and pulping. it is used to break the waste paper into pulp and generate drastic friction force between the pulp fiber and rotor to scale the printing ink from the fiber surface through chemical function and regenerate the pulp consequently. the rotor of this unit is multi-head helical blade rotor having strong paper scraping function. the working concentration is 15% - 18%. during operation, it will generate strong pulp flow from top to bottom and rotational pulp in the tank. the pulp quality is good and the evenness is high. as an excellent paper scraping equipment, this unit is featured in modern design, reasonable and high paper scrap concentration and energy saving etc.
ⅱ. specification and parameters
|
model name |
lgs1 |
lgs2 |
lgs3 |
lgs5 |
lgs8 |
lgs10 |
lgs12 |
lgs15 |
lgs20 |
lgs25 |
lgs30 |
|
nominal capacity m3 |
1 |
2 |
3 |
5 |
8 |
10 |
12 |
15 |
20 |
25 |
30 |
|
inside diameter of tank mm |
1300 |
1600 |
1800 |
2200 |
2500 |
2800 |
3000 |
3500 |
3965 |
4200 |
4500 |
|
production capacity t/d |
3-4 |
6-9 |
9-12 |
15-18 |
20-25 |
30-38 |
40-50 |
50-70 |
70-90 |
90-110 |
160 |
|
working concentration % |
15-18 |
||||||||||
|
speed r/min |
440 |
400 |
400 |
400 |
350 |
330 |
260 |
216 |
200 |
150 |
140 |
|
pulp outlet pipe dia. mm |
φ200 |
φ250 |
ф300 |
ф350 |
ф350 |
ф400 |
ф450 |
ф500 |
ф550 |
ф650 |
dn600 |
|
inlet pipe dia. mm |
φ50 |
φ65 |
φ80 |
φ80 |
φ100 |
φ100 |
φ100 |
φ100 |
φ100 |
φ100 |
ф150 |
|
supporting motor |
y200l2-6/22kw |
y250m-6/37kw |
y280m-6/55kw |
y315s-6/75kw |
y315l1-6/110kw |
y315l2-6/160kw |
y355l3-8/220kw |
y355l-6/250kw |
y450-3-8/400kw |
y500-8/500kw |
560kw |
|
weight of equipment kg |
2000 |
2800 |
3500 |
5000 |
5600 |
6500 |
8000 |
15000 |
15000 |
16500 |
50000 |
|
external dimension (lwh) mm |
2600×1300×2315 |
2750×1600×2600 |
3006×1800×2785 |
3230×2200×3230 |
3290×2800×3350 |
5000×3200×4200 |
5000× 3200× 4200 |
5200× 3610× 4500 |
7500× 4000× 4850 |
8100× 4200× 5300 |
6500×4700×5500 |
