ⅰ. introduction:
hx series fiber recovery machine recovers the fiber in the waste water through the principle of millipore filtration. the filtration by 15 - 20μm pore is called millipore filtration. as mechanical filtering means, millipore filtration is suitable for separating the minim suspended substance (the pulp fiber) in the liquid to the most extent to realize the solid and fluid phase separation. compared with other filtration means, the millipore filtration has smaller filter media gap and higher flow rate with the help of screen mesh centrifugal force under lower water resistance to trap the suspended solid.
this equipment is specially developed to solve the problems of easy to clog, break, difficult to maintain and high secondary investment of available fiber recovery machine. it is one of the best equipment for paper waste handling.
this equipment adopts the technology of new zealand wanquan and is developed against the situation of china. it is widely used for the occasions requiring solid-liquid separation, such as the filtration of domestic sewage, paper making, weaving, printing and dyeing, chemical industry sewage etc. it is especially suitable for the treatment of paper making white water for reuse in a closed cycle.
ⅱ. main performance parameters

          model



parameter

item

hx1

hx2

hx3

hx4

hx5

filtration area (m2)

5

7

9

11

14

filter screen (grit)

60-250

60-250

60-250

60-250

60-250

filtration capacity (t/h)

50-100

80-150

100-200

120-240

150-300

filter cylinder speed (r/min)

4-6

4-6

4-6

4-6

4-6

rinsing pressure (mpa)

0.3

0.3

0.3

0.3

0.3

motor power (kw)

1.1

1.5

1.5

2.2

3

filter cylinder dia. (mm)

φ1000

φ1250

φ1250

φ1500

φ1500

filter cylinder effective length (mm)

1500

2000

2500

3000

3500

weight (t)

1.5

2

2.5

3

3.5

ss removal ratio (%)

70-85

cod removal ratio (%)

35-50

 note: the higher waste water concentration and grit number, the higher ss and cod removal ratio.

name:

details

ⅰ. introduction:
hx series fiber recovery machine recovers the fiber in the waste water through the principle of millipore filtration. the filtration by 15 - 20μm pore is called millipore filtration. as mechanical filtering means, millipore filtration is suitable for separating the minim suspended substance (the pulp fiber) in the liquid to the most extent to realize the solid and fluid phase separation. compared with other filtration means, the millipore filtration has smaller filter media gap and higher flow rate with the help of screen mesh centrifugal force under lower water resistance to trap the suspended solid.
this equipment is specially developed to solve the problems of easy to clog, break, difficult to maintain and high secondary investment of available fiber recovery machine. it is one of the best equipment for paper waste handling.
this equipment adopts the technology of new zealand wanquan and is developed against the situation of china. it is widely used for the occasions requiring solid-liquid separation, such as the filtration of domestic sewage, paper making, weaving, printing and dyeing, chemical industry sewage etc. it is especially suitable for the treatment of paper making white water for reuse in a closed cycle.
ⅱ. main performance parameters

          model



parameter

item

hx1

hx2

hx3

hx4

hx5

filtration area (m2)

5

7

9

11

14

filter screen (grit)

60-250

60-250

60-250

60-250

60-250

filtration capacity (t/h)

50-100

80-150

100-200

120-240

150-300

filter cylinder speed (r/min)

4-6

4-6

4-6

4-6

4-6

rinsing pressure (mpa)

0.3

0.3

0.3

0.3

0.3

motor power (kw)

1.1

1.5

1.5

2.2

3

filter cylinder dia. (mm)

φ1000

φ1250

φ1250

φ1500

φ1500

filter cylinder effective length (mm)

1500

2000

2500

3000

3500

weight (t)

1.5

2

2.5

3

3.5

ss removal ratio (%)

70-85

cod removal ratio (%)

35-50

 note: the higher waste water concentration and grit number, the higher ss and cod removal ratio.
