ⅰ. overview
the high concentration bleaching tower is the bleaching action unit for high consistency pulp and mainly used for the high concentration hydrogen peroxide bleaching. the pulp flows into the tower from the top, stays for a certain time and then discharges from the discharge screw at the tower bottom. compared with moderate concentration hydrogen peroxide bleaching, the high concentration one can more effectively enhance the pulp white content, save hydrogen peroxide consumption and reduce the pulp bleaching cost.
ⅱ. technical features

nominal capacity

10m3

15m3

20m3

40m3

production capacity

10-20t/d

15-30t/d

20-40t/d

40-80t/d

bleaching concentration

20-35%

20-35%

20-35%

20-35%

bleaching temperature

60-95℃

60-95℃

60-95℃

60-95℃

bleaching time

1.5-2h

1.5-2h

1.5-2h

1.5-2h

pulp inlet

100×300mm

100×300mm

100×500mm

150×500mm

pulp outlet

1224×530mm

1680×632mm

1680×632mm

2235×632mm

vent hole

dn80

dn80

dn80

dn80

power supply

yct180-4a/4kw

yct200-4b/7.5kw

yct200-4b/7.5kw

yct200-4b/7.5kw

external dimension (lwh) mm

4880×2010×4740mm

5800×2260×5190mm

5860×2260×5750mm

6420×2680×7100mm

net weight

4200kg

5000kg

6500kg

10500kg

operating weight

15000kg

20000kg

25000kg

35000kg
