ⅰ. overview
dxf single effect fluffer is mainly used to separate the light and heavy impurity in the waste paper stock and perform secondary size degradation for the pulp from the hydrapulpter. through the secondary size degradation, the screen mesh at the hydrapulpter bottom will be increased to enhance the production capacity.
this machine is equivalent to the assembly of a sealed horizontal hydrapulpter and a light and heavy impurity slag separator, which enables it to have compact structure and high efficiency. this machine integrates the functions of size degradation, trash extraction and coarse screening, greatly simplifies the waste paper processing and reduces the energy consumption.
the pulp flows into the tank in the tangential direction and accelerates under the function of impeller to create whirlpool, which will generate centripetal force to make the light impurity accumulate in the whirlpool center while the heavy impurity thrown to the tank wall. the light impurity in the tank center will be discharged through the light impurity discharge pipe valve on the front cover intermittently while the heavy impurity thrown to the tank wall and some pulp will enter the heavy impurity slag separator through the heavy impurity discharge pipe and the pulp whose heavy impurity is removed will return to the pulp inlet pipe. the removed heavy impurity will be collected in the slag separator impurity slot and discharged through the valve periodically.
after the secondary size degradation by the impeller, the pulp will be delivered by the pulp outlet pipe at the rear section sieve plate of the impeller.
ⅱ. technical performance

model

dxf0

dxf1

dxf2

dxf3

dxf4

production capacity t/d

10-20t/d

20-40t/d

40-70t/d

70-100t/d

130t/d

concentration of feeding pulp

≤3%

pulp inlet pressure

0.15-0.25mpa

sieve plate

ф3/ф4……ф6/ф7阶差0.5阶梯孔系列

impeller speed

1300r/min

837r/min

830r/min

800r/min

750r/min

impeller diameter

ф320mm

ф520mm

ф550mm

ф700mm

ф800mm

pulp inlet pipe diameter

dg100

dg125

dg125

dg150

dn250

pulp outlet pipe diameter

dg100

dg125

dg125

dg150

dn250


light impurity discharge pipe diameter

dg65

dg80

dg80

dg80

dn100

heavy impurity discharge pipe diameter

dg65

dg125

dg125

dg150

dn100

motor

y180l-4/22kw
1470r/min

y225m-4/45kw
1480r/min

y250m-4/55kw
1480r/min

y280s-4/75kw
1480r/min

y315s-4/110kw
1480vmin

weight of equipment kg (without motor)

1800kg

3000kg

3500kg

4000kg



external dimension (l×w×h) mm

2650×1860
×1825mm

3050×2267
×2162mm

3200×2650
×2055mm

3460×2620
×2050mm

4310×2265×2090
