the high concentration hydrapulper is the indispensable equipment for wastepaper deinking and pulping. it is used to break the waste paper into pulp and generate drastic friction force between the pulp fiber and rotor to scale the printing ink from the fiber surface through chemical function and regenerate the pulp consequently. the rotor of this unit is multi-head helical blade rotor having strong paper scraping function. the working concentration is 15% - 18%. during operation, it will generate strong pulp flow from top to bottom and rotational pulp in the tank. the pulp quality is good and the evenness is high. as an excellent paper scraping equipment, this unit is featured in modern design, reasonable and high paper scrap concentration and energy saving etc.
ⅱ. specification and parameters
|
name |
nominal capacity m3 |
inside diameter of tank mm |
production capacity t/d |
working concentration % |
speed r/min |
pulp outlet pipe dia. mm |
inlet pipe dia. mm |
supporting motor |
weight of equipment kg |
external dimension (lwh) mm |
|
lgs1 |
1 |
1300 |
3-4 |
15-18 |
440 |
φ200 |
φ50 |
y200l2-6/22kw |
2000 |
2600×1300×2315 |
|
lgs2 |
2 |
1600 |
6-9 |
400 |
φ250 |
φ65 |
y250m-6/37kw |
2800 |
2750×1600×2600 |
|
|
lgs3 |
3 |
1800 |
9-12 |
400 |
ф300 |
φ80 |
y280m-6/55kw |
3500 |
3006×1800×2785 |
|
|
lgs5 |
5 |
2200 |
15-18 |
400 |
ф350 |
φ80 |
y315s-6/75kw |
5000 |
3230×2200×3230 |
|
|
lgs8 |
8 |
2500 |
20-25 |
350 |
ф350 |
φ100 |
y315l1-6/110kw |
5600 |
3290×2800×3350 |
|
|
lgs10 |
10 |
2800 |
30-38 |
330 |
ф400 |
φ100 |
y315l2-6/160kw |
6500 |
5000×3200×4200 |
|
|
lgs12 |
12 |
3000 |
40-50 |
260 |
ф450 |
φ100 |
y355l3-8/220kw |
8000 |
5000×3200×4200 |
|
|
lgs15 |
15 |
3500 |
50-70 |
216 |
ф500 |
φ100 |
y355l-6/250kw |
15000 |
5200×3610×4500 |
|
|
lgs20 |
20 |
3965 |
70-90 |
200 |
ф550 |
φ100 |
y450-3-8/400kw |
15000 |
7500×4000×4850 |
|
|
lgs25 |
25 |
4200 |
90-110 |
150 |
ф650 |
φ100 |
y500-8/500kw |
16500 |
8100×4200× 5300 |
|
|
lgs30 |
30 |
4500 |
160 |
140 |
dn600 |
ф150 |
560kw |
50000 |
6500×4700×5500 |
