poplar and straw pul
 ⅰ.  introduction
the paper quality of paper factory largely depends on the pulping. the devillicate, brooming, swelling, hydration and
cutting of pulp is known as beating. presently, the most common ones are conventional beater and single / double disc high/low concentration pulp grinder. as these equipment will break the fiber, reduce the product quality, impact the enterprise benefits and have less applicability on pulp in particular on waste paper pulp (which contains glue and ink etc.), additional heat dispersion equipment should be provided to remove the glue and ink etc.
the newly developed lgmii series high concentration cone prefiner is new type beating equipment and suitable for the beating of various pulps. in particular, it can solve the beating and cold / heat dispersion of waste paper pulp at the same time. this equipment is produced through the latest patented technology that approaching or meeting the overseas advanced stage and featured in high assembly accuracy, uniform beating quality, low noise, low power consumption, high pulping concentration, less fiber cut, noticeable devillicate and brooming effect and good fiber toughness. it can effectively protect the fiber length of leaf wood and grass and the once pulping can increase the beating degree by 15 - 20°sr. compared with traditional beater and single / double disc pulp grinder, it increases the efficiency by 2 - 3 times. the yield of one lgmii high concentration cone prefiner is equal to the yield of 3 - 4 zdpiiф450 double disc pulp grinders in series. in particular, for the waste paper pulp, it can effectively separate and remove the hot-melt adhesive, glue and ink of the waste paper pulp in addition to high efficiency beating.
ii. main specifications and parameters



specification



parameters

zgmi

-22

zgmi

-30

zgmi

-37

zgmi

-45

zgmi

-55

zgmi

-75

zgmi

-90

zgmi

-110

zgmi

-132

zgmi

-160

zgmi

-200

zgmi

-250

zgmi

-315

production capacity t/d

10-15

12-18

15-22

20-25

25-30

30-45

35-50

45-65

55-75

65-95

80-120

100-150

125-190

pulping concentration (%)

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

15-35

main motor power (kw)

22

30

37

45

55

75

90

110

132

160

200

250

315

rotor speed (rpm)

2940

2950

2950

2970

2970

2970

2970

2980

2980

2980

2980

2980

2980

feeding screw dia. (mm)

ф100

ф100

ф125

ф125

ф125

ф140

ф150

ф150

ф175

ф175

ф200

ф200

ф225

feeding motor power (kw)

1.1

1.1

1.5

1.5

1.5

2.2

2.2

2.2

3

4

5.5

5.5

7.5

feeding port dimension (mm)

200×

100

200×

100

200×

150

200×

150

200×

150

250×

150

300×

150

300×150

300×200

300×200

350×250

350×250

400×300

discharge port dimension (mm)

250×

80

250×

80

300×

80

300×

80

300×

80

300×

80

300×

100

300×100

300×150

300×150

350×200

350×200

400×250
