pulping equipment
your current location : home products pulping equipment
. d- hydrapulper d model hydrapulper
uses / features
d- hydrapulper main feature is the use of the "d" -type tank, saving volts alex rotor , inside and outside the double blades can save energy by 25% , the contact with the rotor of the paper more quickly , at higher frequencies , with the traditional hydraulic broken pulp compared to shorten pulping time , increase production capacity without increasing the power and volume situations. d -type hydraulic pulper rotors and a higher plasma disk pulper tank bottom plane , the rotor is formed around a low pressure area will make the process of crushing the coarse impurities into the slag hole heavier sediment wells.
application / features
the main feature of d-type hydrapulper are the use of the d-type groove and the energy saving vieques rotor, both internal and external leaves 25% energy saving to make waste paper and rotor contact more quickly, more frequently. compared with the traditional hydro-pulper, it could shorten the time of pulp breaking and increase productivity without increasing the volume and momentum .. d-type hydro-pulper rotor and the outlet tray is above the pulper tank surface to form a low-pressure flow surrounding the rotor to make the coarse impurities into the dregs well from the heavy dregs mouth with regularly sending under the use of grab.
the main technical parameters main technical parameters
no. sn name name d -type
an effective volume
effective capacity (m3) 10 15 20 25 30
2 production capacity
production capacity (t / d) 60-90 80-120 140-180 180-230 230-280
3 slurry concentration
pulp concentration (%) 2-5
4 motor model motor model y315l1-6 y355m1-6 y355m2-6 y355l2-6 yl400-8
5 power power (kw) 110 160 185 250 280

name:

details
. d- hydrapulper d model hydrapulper
uses / features
d- hydrapulper main feature is the use of the "d" -type tank, saving volts alex rotor , inside and outside the double blades can save energy by 25% , the contact with the rotor of the paper more quickly , at higher frequencies , with the traditional hydraulic broken pulp compared to shorten pulping time , increase production capacity without increasing the power and volume situations. d -type hydraulic pulper rotors and a higher plasma disk pulper tank bottom plane , the rotor is formed around a low pressure area will make the process of crushing the coarse impurities into the slag hole heavier sediment wells.
application / features
the main feature of d-type hydrapulper are the use of the d-type groove and the energy saving vieques rotor, both internal and external leaves 25% energy saving to make waste paper and rotor contact more quickly, more frequently. compared with the traditional hydro-pulper, it could shorten the time of pulp breaking and increase productivity without increasing the volume and momentum .. d-type hydro-pulper rotor and the outlet tray is above the pulper tank surface to form a low-pressure flow surrounding the rotor to make the coarse impurities into the dregs well from the heavy dregs mouth with regularly sending under the use of grab.
the main technical parameters main technical parameters
no. sn name name d -type
an effective volume
effective capacity (m3) 10 15 20 25 30
2 production capacity
production capacity (t / d) 60-90 80-120 140-180 180-230 230-280
3 slurry concentration
pulp concentration (%) 2-5
4 motor model motor model y315l1-6 y355m1-6 y355m2-6 y355l2-6 yl400-8
5 power power (kw) 110 160 185 250 280
