uses / features
flotation technology is widely used in recent years, drainage and waste water treatment , it can be difficult to effectively remove wastewater floc precipitation frivolous . the device processing capacity, high efficiency , small footprint . simple structure, easy maintenance. eliminate sludge bulking . low temperature , low turbidity , water containing algae and more , using the flotation method to obtain the best results.
application / features
flotation technology in recent years is widely used in the drainage and wastewater treatment, it can effectively remove the frivolous flocs difficult to produce in waste water. it has large capacity, high efficiency less installation area, simple structure easy maintenance. it can eliminate the sludge bulking. for low temperature, low turbidity, with more algae in the water, using the flotation method to obtain the best results.
the main technical parameters main technical parameters
model
type handling capacity
capacity
(m3 / h) dissolved air water
dissolved air (m3 / h) main motor power
main motor power (kw) shaving foam machine power
scratch foam machine power (kw) air compressor power
air compressor power (kw) dissolved gas cylinders specifications
dissolved gas cylinders specifications ( mm )
yw-20 15-20 5-7 7.5 0.37 1.5 φ500 × 1512
yw-30 20-30 6-10 7.5 0.37 1.5 φ500 × 1512
yw-40 30-40 8-13 7.5 0.55 1.5 φ600 × 1880
yw-50 40-50 15-20 7.5 0.55 1.5 φ600 × 1880
yw-60 50-60 18-27 7.5 0.55 1.5 φ600 × 1880
yw-80 70-80 24-32 7.5 0.55 1.5 φ650 × 2034
yw-105 90-105 30-35 15 0.55 3 φ700 × 1980
yw-150 125-150 60-80 22 1.1 3 φ800 × 1980
yw-200 175-200 80-100 22 1.1 3 φ800 × 2100
yw-250 225-250 110-120 22 1.1 3 φ800 × 2400
yw-300 280-300 120-180 37 1.1 5.5 φ1000 × 2900
products
dissolved air flotation machine sewage treatment equipment products 造纸机械|压力筛|杨木化机浆|废纸脱墨|利丰机械|山东省诸城市利丰机械有限公司-凯发ag旗舰厅登录网址下载
| contact |
|
tel：0536-6061832 |
sewage treatment equ
uses / features
flotation technology is widely used in recent years, drainage and waste water treatment , it can be difficult to effectively remove wastewater floc precipitation frivolous . the device processing capacity, high efficiency , small footprint . simple structure, easy maintenance. eliminate sludge bulking . low temperature , low turbidity , water containing algae and more , using the flotation method to obtain the best results.
application / features
flotation technology in recent years is widely used in the drainage and wastewater treatment, it can effectively remove the frivolous flocs difficult to produce in waste water. it has large capacity, high efficiency less installation area, simple structure easy maintenance. it can eliminate the sludge bulking. for low temperature, low turbidity, with more algae in the water, using the flotation method to obtain the best results.
the main technical parameters main technical parameters
model
type handling capacity
capacity
(m3 / h) dissolved air water
dissolved air (m3 / h) main motor power
main motor power (kw) shaving foam machine power
scratch foam machine power (kw) air compressor power
air compressor power (kw) dissolved gas cylinders specifications
dissolved gas cylinders specifications ( mm )
yw-20 15-20 5-7 7.5 0.37 1.5 φ500 × 1512
yw-30 20-30 6-10 7.5 0.37 1.5 φ500 × 1512
yw-40 30-40 8-13 7.5 0.55 1.5 φ600 × 1880
yw-50 40-50 15-20 7.5 0.55 1.5 φ600 × 1880
yw-60 50-60 18-27 7.5 0.55 1.5 φ600 × 1880
yw-80 70-80 24-32 7.5 0.55 1.5 φ650 × 2034
yw-105 90-105 30-35 15 0.55 3 φ700 × 1980
yw-150 125-150 60-80 22 1.1 3 φ800 × 1980
yw-200 175-200 80-100 22 1.1 3 φ800 × 2100
yw-250 225-250 110-120 22 1.1 3 φ800 × 2400
yw-300 280-300 120-180 37 1.1 5.5 φ1000 × 2900
flotation technology is widely used in recent years, drainage and waste water treatment , it can be difficult to effectively remove wastewater floc precipitation frivolous . the device processing capacity, high efficiency , small footprint . simple structure, easy maintenance. eliminate sludge bulking . low temperature , low turbidity , water containing algae and more , using the flotation method to obtain the best results.
application / features
flotation technology in recent years is widely used in the drainage and wastewater treatment, it can effectively remove the frivolous flocs difficult to produce in waste water. it has large capacity, high efficiency less installation area, simple structure easy maintenance. it can eliminate the sludge bulking. for low temperature, low turbidity, with more algae in the water, using the flotation method to obtain the best results.
the main technical parameters main technical parameters
model
type handling capacity
capacity
(m3 / h) dissolved air water
dissolved air (m3 / h) main motor power
main motor power (kw) shaving foam machine power
scratch foam machine power (kw) air compressor power
air compressor power (kw) dissolved gas cylinders specifications
dissolved gas cylinders specifications ( mm )
yw-20 15-20 5-7 7.5 0.37 1.5 φ500 × 1512
yw-30 20-30 6-10 7.5 0.37 1.5 φ500 × 1512
yw-40 30-40 8-13 7.5 0.55 1.5 φ600 × 1880
yw-50 40-50 15-20 7.5 0.55 1.5 φ600 × 1880
yw-60 50-60 18-27 7.5 0.55 1.5 φ600 × 1880
yw-80 70-80 24-32 7.5 0.55 1.5 φ650 × 2034
yw-105 90-105 30-35 15 0.55 3 φ700 × 1980
yw-150 125-150 60-80 22 1.1 3 φ800 × 1980
yw-200 175-200 80-100 22 1.1 3 φ800 × 2100
yw-250 225-250 110-120 22 1.1 3 φ800 × 2400
yw-300 280-300 120-180 37 1.1 5.5 φ1000 × 2900
